ZK6752DFA9

Coaches

  • 7470*2340*2970/3100(A/C)

    Dimension(mm)

  • 8450

    G.V.W.(kg)

  • 30+1

    Seats

ZK6752DFA9

Good-looking appearance with good safety performance



Rear-mounted engine style and front air grille with chrome molded piece are full of aesthetic appeal.

Both the width and height of the vehicle are increased to create a spacious and comfortable environment for passengers.

Air intake of the engine through the side wall adapts to the intake demand under various road conditions.

Ultra large side windows and large curved front windshield offer you a broader vision.

New-style rabbit ear shaped rearview mirrors feature wide visual field and no blind spots.

Improving operating income with reliability and durability



Defrosting system with residual heat of engine enables the unimpeded to run  in frosty weather.

Adjustable driver seat is very comfortable.

ZK6752DFA9
  • ZK6752DFA9

Harmonious color matching and pleasant trip

Side panel with PVC veneers is easy to clean.
Sunk floor structure at the aisle area, as well as simple but practical guard rails, facilitates the passage.
Roof top with molded linen materials is high-end and eco-friendly.
Roof hatch can refresh the air in the passenger compartment as required.
The design of softening dashboard is more humane.

ZK6752DFA9ZK6752DFA9



Bus parameters
ZK6752DFA9

Basic parameters

  • Engine modelYC4E140-20
  • Dimension(mm)7470*2340*2970/3100(A/C)
  • G.V.W.(kg)8450
  • Luggage compartment(M3)0-1.5
  • Max. speed(km/h)105

Chassis

  • Chassis manufacturerZhengzhou Yutong Bus Co., Ltd
  • ClutchOuter diameter of friction lining 362, hydraulic remote control with air assistance
  • Gearbox6-speed manual gearbox
  • Brake systemDual circuit pneumatic brake, energy storage spring parking brake
  • Suspension systemLeaf spring, bidirectional telescopic shock absorber
  • Tire8.25R16
  • Fuel tank (L)140
  • LHD/RHDLHD
  • Others-

Body

  • Seats30+1
  • InteriorsSplit-type interior luggage rack
  • Air conditioner (A/C)Optional: non-independent roof-mounted A/C (16000kcal/h)
  • Heating systemNone
  • Audio & video systemOptional: SD memory card player, 17" LCD monitor in the front
  • Service partsNone
  • Other facilitiesWindshield wiper, driver door
