ZK6938HQ (Intercity bus)

Intercity buses

  • 9350*2500*3340

    Dimension(mm)

  • 13800

    G.V.W.(kg)

  • 39+1, adjustable backrest, breadthwise adjustable

    Seats

ZK6938HQ (Intercity bus)

Big Room, Big Boom

Larger luggage space: the volume of the optimized luggage compartment is 13% larger than that of the vehicles of same kind and can carry more luggage, bringing more convenience for passengers.

Enlarged passenger compartment: voluminous interior space, widened aisle and more optional seat types provide you with a better ride comfort. Optimized layout of seats, luggage rack and other accessories maximizes the interior space.

Ultra large driver space: flat driver zone facilitates the cleaning and placement of items. Optimized dashboard provides an easy access to boarding.

Advanced structure ensures the quality

Fuel tank of 200L extends the driving range;

Inheriting the good genes of Yutong medium-sized products, the vehicle has full rounded appearance with a more approachable feeling;

NVH mute technology, six-airbag suspension, lowered body weight and optimized power matching provide you with a better ride comfort.

ZK6938HQ (Intercity bus)
  • ZK6938HQ (Intercity bus)

More Concern, More Benefits

Six-way adjustable driver seat: six-way adjustable driver seat with backrest inclination makes it easy for drivers to find the optimal position;

Pressure-balanced seat: with the ergonomic design, the ride comfort of passengers is greatly improved;

Fresh air circulation technology of A/C: when the compressor of air conditioner is not turned on, the air inside the vehicle can be totally replaced in five minutes averagely through triggering the air circulation device, which not only improves the comfort of the passenger compartment, but also cuts the fuel consumption.

ZK6938HQ (Intercity bus)ZK6938HQ (Intercity bus)
Bus parameters
ZK6938HQ (Intercity bus)

Basic parameters

  • Engine modelISB6.7E6 28
  • Dimension(mm)9350*2500*3340
  • G.V.W.(kg)13800
  • Luggage compartment(M3)4
  • Max. speed(km/h)100

Chassis

  • Chassis manufacturerZhengzhou Yutong Bus Co., Ltd
  • ClutchOuter diameter of friction lining 395, hydraulic remote control with air assistance
  • GearboxZF AT (ZF manual transmission)
  • Brake systemDual circuit pneumatic brake, energy storage spring parking brake, ABS+ESC, retarder
  • Suspension systemAir suspension, bidirectional telescopic shock absorber
  • Tire265/70R19.5
  • Fuel tank (L)250
  • LHD/RHD-
  • OthersThermal management system of engine

Body

  • Seats39+1, adjustable backrest, breadthwise adjustable
  • InteriorsIntegral air duct, reading lamp, air outlet, curtain
  • Air conditioner (A/C)Cooling & heating A/C (32000kcal/h)
  • Heating systemImported independent water heating
  • Audio & video systemDVD player, 19" LCD monitor in the front
  • Service partsElectronic clock, refrigerator
  • Other facilitiesWindshield wiper, remote control lock
